Supply voltage | ||
Load voltage L+ | ||
● Rated value (DC) | 24 V; From power module | |
● Reverse polarity protection | Yes | |
Input current | ||
from load voltage L+ (without load), max. | 30 mA | |
from backplane bus 3.3 V DC, max. | 10 mA | |
Output voltage | ||
Power supply to the transmitters | ||
● present | Yes | |
● short-circuit proof | Yes | |
Power loss | ||
Power loss, typ. | 0.6 W | |
Address area | ||
Address space per module | ||
● Address space per module, max. | 8 byte | |
Analog inputs | ||
Number of analog inputs | 4; 2 for 3 or 4-wire connection | |
permissible input voltage for voltage input (destruction limit), max. | 9 V | |
Constant measurement current for resistance-type transmitter, typ. | 1.67 mA | |
Cycle time (all channels) max. | Number of active channels per module x basic conversion time | |
Technical unit for temperature measurement adjustable | No | |
Input ranges | ||
● Voltage | No | |
● Current | No | |
● Thermocouple | No | |
● Resistance thermometer | Yes | |
● Resistance | Yes | |
Input ranges (rated values), resistance thermometer | ||
● Ni 100 | Yes; Standard/climate | |
● Input resistance (Ni 100) | 2 000 kΩ | |
● Pt 100 | Yes; Standard/climate | |
● Input resistance (Pt 100) | 2 000 kΩ | |
Input ranges (rated values), resistors | ||
● 0 to 150 ohms | Yes | |
● Input resistance (0 to 150 ohms) | 2 000 kΩ | |
● 0 to 300 ohms | Yes | |
● Input resistance (0 to 300 ohms) | 2 000 kΩ | |
● 0 to 600 ohms | Yes | |
● Input resistance (0 to 600 ohms) | 2 000 kΩ | |
Characteristic linearization | ||
● parameterizable | Yes; for Pt100, Ni100 | |
— for resistance thermometer | Pt100 (standard, climatic range), Ni100 (standard, climatic range) | |
Cable length | ||
● shielded, max. | 200 m | |
Analog value generation for the inputs | ||
Measurement principle | integrating | |
Integration and conversion time/resolution per channel | ||
● Resolution with overrange (bit including sign), max. | 16 bit; 150 ohms: 14 bits; 300, 600 ohms: 15 bits, Pt100, Ni100: 16 bits | |
● Integration time, parameterizable | Yes | |
● Integration time (ms) | 16,7 / 20 ms | |
● Interference voltage suppression for interference frequency f1 in Hz | 50 / 60 Hz | |
● Conversion time (per channel) | 66 / 80 ms; additional conversion time for diagnostic wire break test | |
Smoothing of measured values | ||
● parameterizable | Yes; In four stages by means of digital filtering | |
● Step: None | Yes; 1 x cycle time | |
● Step: low | Yes; 4 x cycle time | |
● Step: Medium | Yes; 32 x cycle time | |
● Step: High | Yes; 64 x cycle time | |
Encoder | ||
Connection of signal encoders | ||
● for resistance measurement with two-wire connection | Yes | |
● for resistance measurement with three-wire connection | Yes | |
● for resistance measurement with four-wire connection | Yes | |
Errors/accuracies | ||
Linearity error (relative to input range), (+/-) | 0.01 % | |
Temperature error (relative to input range), (+/-) | 0.005 %/K | |
Crosstalk between the inputs, min. | -50 dB | |
Repeat accuracy in steady state at 25 °C (relative to input range), (+/-) | 0.05 % | |
Operational error limit in overall temperature range | ||
● Resistance thermometer, relative to input range, (+/-) | 0.6 % | |
Basic error limit (operational limit at 25 °C) | ||
● Resistance thermometer, relative to input range, (+/-) | 0.4 % | |
Interference voltage suppression for f = n x (f1 +/- 1 %), f1 = interference frequency | ||
● Series mode interference (peak value of interference < rated value of input range), min. | 70 dB | |
● Common mode interference (USS < 2.5 V) , min. | 90 dB | |
Isochronous mode | ||
Isochronous operation (application synchronized up to terminal) | No | |
Interrupts/diagnostics/status information | ||
Diagnostic messages | ||
● Wire-break | Yes | |
● Group error | Yes | |
● Overflow/underflow | Yes | |
Diagnostics indication LED | ||
● Group error SF (red) | Yes | |
Parameter | ||
Diagnostics wire break | Disable / enable | |
Measurement type/range | deactivated/150 ohms/; 300 ohms/600 ohms/ Pt100 climatic/ Pt100 standard; Ni100 standard / Ni100 climatic, 2, 3 or 4-wire | |
Group diagnostics | Disable / enable | |
Overflow/underflow | Disable / enable | |
Potential separation | ||
Potential separation analog inputs | ||
● between the channels | No | |
● between the channels and backplane bus | Yes | |
● Between the channels and load voltage L+ | Yes | |
Permissible potential difference | ||
between MANA and M internally (UISO) | 75 V DC/60 V AC | |
Isolation | ||
Isolation tested with | 500 V DC | |
Dimensions | ||
Width | 15 mm | |
Height | 81 mm | |
Depth | 52 mm | |
Weights | ||
Weight | 40 g | |
last modified: | 10/25/2017 |
