Original new siemens 6AV2123-2GB03-0AX0 SIMATIC HMI KTP700 BASIC
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
6AV2123-2GB03-0AX0
SIMATIC HMI KTP700 BASIC
SIMATIC HMI, KTP700 BASIC, BASIC PANEL, KEY AND TOUCH OPERATION, 7" TFT DISPLAY, 65536 COLORS, PROFINET INTERFACE, CONFIGURATION FROM WINCC BASIC V13/ STEP7 BASIC V13, CONTAINS OPEN SOURCE SW WHICH IS PROVIDED FREE OF CHARGE FOR DETAILS SEE CD
Technical data
| SIMATIC HMI, KTP700 BASIC, BASIC PANEL, KEY AND TOUCH OPERATION, 7" TFT DISPLAY, 65536 COLORS, PROFINET INTERFACE, CONFIGURATION FROM WINCC BASIC V13/ STEP7 BASIC V13, CONTAINS OPEN SOURCE SW WHICH IS PROVIDED FREE OF CHARGE FOR DETAILS SEE CD | ||
| General information | ||
| Product type designation | KTP700 Basic color PN | |
| Display | ||
| Design of display | TFT widescreen display, LED backlighting | |
| Screen diagonal | 7 in | |
| Display width | 154.1 mm | |
| Display height | 85.9 mm | |
| Number of colors | 65 536 | |
| Resolution (pixels) | ||
| ● Horizontal image resolution | 800 Pixel | |
| ● Vertical image resolution | 480 Pixel | |
| Backlighting | ||
| ● MTBF backlighting (at 25 °C) | 20 000 h | |
| ● Backlight dimmable | Yes | |
| Control elements | ||
| Keyboard fonts | ||
| ● Function keys | ||
| — Number of function keys | 8 | |
| ● Keys with LED | No | |
| ● System keys | No | |
| ● Numeric keyboard | Yes; Onscreen keyboard | |
| ● alphanumeric keyboard | Yes; Onscreen keyboard | |
| Touch operation | ||
| ● Design as touch screen | Yes | |
| Installation type/mounting | ||
| Mounting position | Horizontal, vertical | |
| Mounting in portrait format possible | Yes | |
| Mounting in landscape format possible | Yes | |
| maximum permissible angle of inclination without external ventilation | 35° | |
| Supply voltage | ||
| Type of supply voltage | DC | |
| Rated value (DC) | 24 V | |
| permissible range, lower limit (DC) | 19.2 V | |
| permissible range, upper limit (DC) | 28.8 V | |
| Input current | ||
| Current consumption (rated value) | 230 mA | |
| Starting current inrush I²t | 0.2 A²·s | |
| Power | ||
| Active power input, typ. | 5.5 W | |
| Processor | ||
| Processor type | ARM | |
| Memory | ||
| Flash | Yes | |
| RAM | Yes | |
| Memory available for user data | 10 Mbyte | |
| Type of output | ||
| Acoustics | ||
| ● Buzzer | Yes | |
| ● Speaker | No | |
| Time of day | ||
| Clock | ||
| ● Hardware clock (real-time) | Yes | |
| ● Software clock | Yes | |
| ● retentive | Yes; Back-up duration typically 6 weeks | |
| ● synchronizable | Yes | |
| Interfaces | ||
| Number of industrial Ethernet interfaces | 1 | |
| Number of RS 485 interfaces | 0 | |
| Number of RS 422 interfaces | 0 | |
| Number of RS 232 interfaces | 0 | |
| Number of USB interfaces | 1; Up to 16 GB | |
| Number of 20 mA interfaces (TTY) | 0 | |
| Number of parallel interfaces | 0 | |
| Number of other interfaces | 0 | |
| Number of SD card slots | 0 | |
| With software interfaces | No | |
| Industrial Ethernet | ||
| ● Industrial Ethernet status LED | 2 | |
| Protocols | ||
| PROFINET | Yes | |
| Supports protocol for PROFINET IO | No | |
| IRT | No | |
| MRP | No | |
| PROFIBUS | No | |
| MPI | No | |
| Protocols (Ethernet) | ||
| ● TCP/IP | Yes | |
| ● DHCP | Yes | |
| ● SNMP | Yes | |
| ● DCP | Yes | |
| ● LLDP | Yes | |
| WEB characteristics | ||
| ● HTTP | No | |
| ● HTML | No | |
| Further protocols | ||
| ● CAN | No | |
| ● EtherNet/IP | Yes | |
| ● MODBUS | Yes; Modicon (MODBUS TCP/IP) | |
| Interrupts/diagnostics/status information | ||
| Diagnostic messages | ||
| ● Diagnostic information readable | No | |
| EMC | ||
| Emission of radio interference acc. to EN 55 011 | ||
| ● Limit class A, for use in industrial areas | Yes | |
| ● Limit class B, for use in residential areas | No | |
| Degree and class of protection | ||
| IP (at the front) | IP65 | |
| Enclosure Type 4 at the front | Yes | |
| Enclosure Type 4x at the front | Yes | |
| IP (rear) | IP20 | |
| Standards, approvals, certificates | ||
| CE mark | Yes | |
| cULus | Yes | |
| RCM (formerly C-TICK) | Yes | |
| KC approval | Yes | |
| Marine approval | ||
| ● Germanischer Lloyd (GL) | Yes | |
| ● American Bureau of Shipping (ABS) | Yes | |
| ● Bureau Veritas (BV) | Yes | |
| ● Det Norske Veritas (DNV) | Yes | |
| ● Lloyds Register of Shipping (LRS) | Yes | |
| ● Nippon Kaiji Kyokai (Class NK) | Yes | |
| ● Polski Rejestr Statkow (PRS) | No | |
| ● Chinese Classification Society (CCS) | No | |
| Use in hazardous areas | ||
| ● ATEX Zone 2 | No | |
| ● ATEX Zone 22 | No | |
| ● IECEx Zone 2 | No | |
| ● IECEx Zone 22 | No | |
| ● cULus Class I Zone 1 | No | |
| ● cULus Class I Zone 2, Division 2 | No | |
| ● FM Class I Division 2 | No | |
| Ambient conditions | ||
| Ambient temperature during operation | ||
| ● Operation (vertical installation) | ||
| — For vertical installation, min. | 0 °C | |
| — For vertical installation, max. | 50 °C | |
| ● Operation (max. tilt angle) | ||
| — At maximum tilt angle, min. | 0 °C | |
| — At maximum tilt angle, min. | 40 °C | |
| ● Operation (vertical installation, portrait format) | ||
| — For vertical installation, min. | 0 °C | |
| — For vertical installation, max. | 40 °C | |
| ● Operation (max. tilt angle, portrait format) | ||
| — At maximum tilt angle, min. | 0 °C | |
| — At maximum tilt angle, min. | 35 °C | |
| Ambient temperature during storage/transportation | ||
| ● min. | -20 °C | |
| ● max. | 60 °C | |
| Relative humidity | ||
| ● Operation, max. | 90 %; no condensation | |
| Operating systems | ||
| proprietary | Yes | |
| pre-installed operating system | ||
| ● Windows CE | No | |
| Configuration | ||
| Message indicator | Yes | |
| Alarm system (incl. buffer and acknowledgment) | Yes | |
| Process value display (output) | Yes | |
| Process value default (input) possible | Yes | |
| Recipe management | Yes | |
| Configuration software | ||
| ● STEP 7 Basic (TIA Portal) | Yes; via integrated WinCC Basic (TIA Portal) | |
| ● STEP 7 Professional (TIA Portal) | Yes; via integrated WinCC Basic (TIA Portal) | |
| ● WinCC flexible Compact | No | |
| ● WinCC flexible Standard | No | |
| ● WinCC flexible Advanced | No | |
| ● WinCC Basic (TIA Portal) | Yes | |
| ● WinCC Comfort (TIA Portal) | Yes | |
| ● WinCC Advanced (TIA Portal) | Yes | |
| ● WinCC Professional (TIA Portal) | Yes | |
| Languages | ||
| Online languages | ||
| ● Number of online/runtime languages | 10 | |
| Project languages | ||
| ● Languages per project | 32 | |
| Functionality under WinCC (TIA Portal) | ||
| Libraries | Yes | |
| Applications/options | ||
| ● Web browser | Yes | |
| ● SIMATIC WinCC Sm@rtServer | Yes; Available with WinCC (TIA Portal) V14 or higher | |
| Number of Visual Basic Scripts | No | |
| Task planner | Yes | |
| ● time-controlled | No | |
| ● task-controlled | Yes | |
| Help system | Yes | |
| ● Number of characters per info text | 500 | |
| Message system | ||
| ● Number of alarm classes | 32 | |
| ● Bit messages | ||
| — Number of bit messages | 1 000 | |
| ● Analog messages | ||
| — Number of analog messages | 25 | |
| ● S7 alarm number procedure | No | |
| ● System messages HMI | Yes | |
| ● System messages, other (SIMATIC S7, Sinumerik, Simotion, etc.) | Yes; System message buffer of the SIMATIC S7-1200 and S7-1500 | |
| ● Number of characters per message | 80 | |
| ● Number of process values per message | 8 | |
| ● Acknowledgment groups | Yes | |
| ● Message indicator | Yes | |
| ● Message buffer | ||
| — Number of entries | 256 | |
| — Circulating buffer | Yes | |
| — retentive | Yes | |
| — maintenance-free | Yes | |
| Recipe management | ||
| ● Number of recipes | 50 | |
| ● Data records per recipe | 100 | |
| ● Entries per data record | 100 | |
| ● Size of internal recipe memory | 256 kbyte | |
| ● Recipe memory expandable | No | |
| Variables | ||
| ● Number of variables per device | 800 | |
| ● Number of variables per screen | 100 | |
| ● Limit values | Yes | |
| ● Multiplexing | Yes | |
| ● Structures | No | |
| ● Arrays | Yes | |
| Images | ||
| ● Number of configurable images | 250 | |
| ● Permanent window/default | Yes | |
| ● Global image | Yes | |
| ● Pop-up images | No | |
| ● Slide-in images | No | |
| ● Image selection by PLC | Yes | |
| ● Image number in the PLC | Yes | |
| Image objects | ||
| ● Number of objects per image | 100 | |
| ● Text fields | Yes | |
| ● I/O fields | Yes | |
| ● Graphic I/O fields (graphics list) | Yes | |
| ● Symbolic I/O fields (text list) | Yes | |
| ● Date/time fields | Yes | |
| ● Switches | Yes | |
| ● Buttons | Yes | |
| ● Graphic display | Yes | |
| ● Icons | Yes | |
| ● Geometric objects | Yes | |
| Complex image objects | ||
| ● Number of complex objects per screen | 10 | |
| ● Alarm view | Yes | |
| ● Trend view | Yes | |
| ● User view | Yes | |
| ● Status/control | No | |
| ● Sm@rtClient view | No | |
| ● Recipe view | Yes | |
| ● f(x) trend view | No | |
| ● System diagnostics view | Yes; System message buffer of the SIMATIC S7-1200 and S7-1500 | |
| ● Media Player | No | |
| ● HTML browser | Yes | |
| ● PDF display | No | |
| ● IP camera display | No | |
| ● Bar graphs | Yes | |
| ● Sliders | No | |
| ● Pointer instruments | No | |
| ● Analog/digital clock | No | |
| Lists | ||
| ● Number of text lists per project | 300 | |
| ● Number of entries per text list | 100 | |
| ● Number of graphics lists per project | 100 | |
| ● Number of entries per graphics list | 100 | |
| Archiving | ||
| ● Number of archives per device | 2; One message and one process value archive | |
| ● Number of entries per archive | 10 000 | |
| ● Message archive | Yes | |
| ● Process value archive | Yes | |
| ● Archiving methods | ||
| — Sequential archive | Yes | |
| — Short-term archive | Yes | |
| ● Memory location | ||
| — Memory card | No | |
| — USB memory | Yes | |
| — Ethernet | No | |
| ● Data storage format | ||
| — CSV | No | |
| — TXT | Yes | |
| — RDB | No | |
| Security | ||
| ● Number of user groups | 50 | |
| ● Number of user rights | 32 | |
| ● Number of users | 50 | |
| ● Password export/import | Yes | |
| ● SIMATIC Logon | No | |
| Character sets | ||
| ● Keyboard fonts | ||
| — US English | Yes | |
| Transfer (upload/download) | ||
| ● MPI/PROFIBUS DP | No | |
| ● USB | No | |
| ● Ethernet | Yes | |
| ● using external storage medium | Yes | |
| Process coupling | ||
| ● S7-1200 | Yes | |
| ● S7-1500 | Yes | |
| ● S7-200 | Yes | |
| ● S7-300/400 | Yes | |
| ● LOGO! | Yes | |
| ● WinAC | Yes | |
| ● SINUMERIK | Yes; No access to NCK data | |
| ● SIMOTION | Yes | |
| ● Allen Bradley (EtherNet/IP) | Yes | |
| ● Allen Bradley (DF1) | No | |
| ● Mitsubishi (MC TCP/IP) | Yes | |
| ● Mitsubishi (FX) | No | |
| ● OMRON (FINS TCP) | No | |
| ● OMRON (LINK/Multilink) | No | |
| ● Modicon (Modbus TCP/IP) | Yes | |
| ● Modicon (Modbus) | No | |
| Service tools/configuration aids | ||
| ● Backup/Restore manually | Yes | |
| ● Backup/Restore automatically | No | |
| ● Simulation | Yes | |
| ● Device switchover | Yes | |
| Peripherals/Options | ||
| Peripherals | ||
| ● Printer | No | |
| ● SIMATIC HMI MM memory card: Multi Media Card | No | |
| ● SIMATIC HMI SD memory card: Secure Digital memory card | No | |
| ● SIMATIC HMI CF memory card Compact Flash Card | No | |
| ● USB memory | Yes | |
| ● SIMATIC IPC USB Flashdrive (USB stick) | Yes | |
| ● SIMATIC HMI USB stick | Yes | |
| Mechanics/material | ||
| Enclosure material (front) | ||
| ● Plastic | Yes | |
| ● Aluminum | No | |
| ● Stainless steel | No | |
| Dimensions | ||
| Width of the housing front | 214 mm | |
| Height of housing front | 158 mm | |
| Mounting cutout, width | 197 mm | |
| Mounting cutout, height | 141 mm | |
| Overall depth | 39 mm | |
| Weights | ||
| Weight without packaging | 780 g | |
| Weight incl. packaging | 990 g | |
| last modified: | 10/26/2017 | |
Contact Details
